RB250HS

Features:

  • Electromechanical limit switch
  • BlueBUS Technology allows the control and power of seven pairs of photocells from the MoonBus Series
  • Optional PS124 Battery Back-up
  • Equipped with a temperature sensor to adapt the motor power to climatic changes
  • Master/ slave selection automatically synchronised
  • 8 Programming levels
  • Acceleration adjustment





Details
Protection Level (IP) 44
Working Temp. (°C Min/Max) -20 ÷ +50
Electrical Data
Absorption (A) 2.1
Power (W) 430
Power Supply (Vac 50/60 Hz) 230
Gate Specifications
Automation Type Sliding
Kit Type Single
Max. Gate Leaf Length (M) 8
Max. Gate Weight (KG) 250
Performance Data
Speed (m/s) >> 0.4 <<
Torque (Nm) 310
Work Cycle (cycles/hour) 50
