Resolution |
540 TVL |
|
Pick up Element |
1/3" H.R. Image sensor |
|
Number of Pixel |
728(H) x 488(V) |
|
Min. Illumination |
0.1Lux (15 IRE) / F2.0; 0 Lux (IR ON) |
|
S/N Ratio |
More than 48dB (AGC off) |
|
Electronic Shutter |
1/60 (1/50) to 1/900,000 sec. |
|
Lens |
f3.8mm ~ f9.5mm |
|
Lens Angle |
85.4° ~ 36° |
|
IRIS Mode |
AES |
|
White Balance |
ATW |
|
AGC |
Auto |
|
IP Rating |
IP 66 |
|
Operating Temperature |
-10°C~40°C |
|
Video Output |
1.0 Vp-p composite, 75Ω |
|
Power Source(±10%) |
DC12V |
|
Current Consumption(±10%) |
63.5mA(IR OFF), 170mA (IR ON) |
|
Dimension (mm)** |
60(H) x 97(Φ) |
