Pick up Element |
1/3" H.R. Color CCD image sensor |
|
Number of Pixel |
768(H) x 494(V) <NTSC> / 752(H) x 582(V) <PAL> |
|
Resolution |
520 TV Lines |
|
Min. Illumination |
0.1Lux / F2.0 / 0Lux (IR ON) |
|
IR LED |
35 Units |
|
Effective Range |
35 Meters |
|
S/N Ratio |
More than 48dB (AGC off) |
|
Electronic Shutter |
1/60 (1/50) to 1/100,000 sec. |
|
Lens |
f3.6mm / F2.0 |
|
Lens Angle |
92.6° |
|
Iris Mode |
AES |
|
AGC |
AUTO |
|
White Balance |
ATW |
|
Video Output |
1.0Vp-p composite, 75Ω |
|
Power Source |
DC12V±10% |
|
IP Rating |
IP67 |
|
Video Output |
1.0 Vp-p composite, 75Ω |
|
Power Source (±10%) |
DC12V |
|
Current Consumption (±10%) |
70mA (IR OFF) / 4000mA (IR ON) |
|
Dimensions (mm) |
142(H) x 75(D) |
|
weight |
430g |
