Pick up Element |
1/3" H.R. color CCD image sensor |
|
Number of Pixel |
771(H) x 492(V) <NTSC> / 753(H) x 582(V) <PAL> |
|
Resolution |
520 TV Lines |
|
Min. Illumination |
0.1 Lux / F2.0, 0Lux (IR ON) |
|
IR LED |
21 units |
|
Effective Range |
Up to 15 Meters |
|
S/N Ratio |
More than 48dB (AGC OFF) |
|
Electronic Shutter |
1/60 (1/50) to 1/100,000 sec. |
|
Lens |
f3.6mm / F2.0 |
|
Lens Angle |
92.6° |
|
IRIS Mode |
AES |
|
White Balance |
ATW |
|
Video Output |
1.0 Vp-p composite, 75Ω |
|
Power Source (±10%) |
DC12V |
|
Current Consumption (±10%) |
70mA (IR OFF), 220mA (IR ON) |
|
Dimensions (mm)** |
94.1(Θ) x 70.7(H) |
