SPECIFICATIONS: |
• Power Source: 24V DC – use PS‑2420UL • Communication: Hands-free (VOX) or handset (full-duplex) • Video: Display 7" color LCD touchscreen • Picture Memory: Internal / Built‑In: record max. 20 calls (6 images per call) with up to 5 calls protected from overwriting SD / SDHC card: record max. 1,000 calls (40 images per call) with up to 100 calls protected from overwriting • Camera: Type: 1/4" color CMOS View Area: 100° vert. x 170° horiz. • Door Release: N/O dry contact, 24V AC/DC, 500mA – use EL‑12S (use RY‑24L for larger contact rating and use RY‑3DL for 3~4 doors) • Wire Type: Door Station to Master Station: 2‑cond., mid cap, solid, non‑shielded – use Aiphone #871802 Power Supply to Master Station: 2‑cond., mid cap, solid, non‑shielded – use Aiphone #871802 Master Station to Adaptor: CAT‑5e or CAT‑6 Adaptor to Sub Master Station: CAT‑5e or CAT‑6 • Distance: Door Station to Master Station: 330', Master Station to Distribution Adaptor: 650', Distribution Adaptor to Sub Master Station: 165', Power Supply to Master Station: 16'(22AWG) 33'(18AWG), Power Supply to Distribution Adaptor: 16'(22AWG) 33'(18AWG) |
