GR-200DC
GR-200DC, antelope operator, it is like the name it calls. Adopting DC motor, it provides the high efficiency and transmission to active the turning both open and
close in fast speed. In addition, there is also the protection for over-heating function when the temperature is hot.
As for the controller, it is developed by latest digital accessories to make it so that operation in open and close can be managed well intellectually.
Thus, GR-200DC is the common operator which can be applied by many different public spots. Fabricator can also free adjust any idea function from its micro-computer controller in order to matching the requirement for every public spots.
Features:
1.Automatic return device
2.Multi-function control system comfiguration
3.Device strong lock function stable noise-free
4.Small frictional resistance, longlife
specifications:
| Function | Single | Bi-parting |
| Loading weight | 90kgs ~120kgs. | 150kgs. (75kgs x 2) |
| Specification / size | DW=400~1500 mm | DW=400~1500 mm x2 |
| Speed in open / close | 200~550mm /sec close/open can be adjusted | |
| Micro-computer controller | Super-compact design in controller block with 8 digital | |
| Driving belt | 7.5M with teeth (width 15m/m) | |
| Hold opening time | 0.1 ~ 10 seconds | |
| Slow speed | 3~6cm/sec/leaf (adjustable) | |
| Safety protection | Automatic open when meets obstacle in open or close | |
| Average consume voltage | 100 W | |
| Motor starting power | 140watt | |
| Temperature range | -20 degree C to 50 degree | |
| Manual opening force | below 4.5 kgs. | |
| Power active | AC 110v ~ AC220v 50/60 Hz | |
| Application | Supermarket, shopping mall, front-store, hospital, bank, Hotel, office, airport | |
| Optional peripheral accessories | Functional selector, safety beam sensor, password lock, Electric-lock, touch sensor, buzzer, remote control | |
