Pick-up Element |
1/2.8" SONY CMOS image sensor |
|
Number of Pixels |
1936(H) × 1096(V) |
|
Video Frame Rate |
1080P@30fps / 1080P@25fps |
|
Min. Illumination |
0.1 Lux / F1.8, 0 Lux (IR LED ON) |
|
S/N Ratio |
More than 48dB (AGC OFF) |
|
Shutter Speed |
1/10,000 ~ 1/7.5 (Slow shutter) |
|
Lens |
f3.6mm / F1.8 |
|
Lens Angle |
87° (Horizontal) / 46° (Vertical) / 104° (Diagonal) |
|
IR LED |
1 unit |
|
IR Effective Distance |
Up to 15 meters |
|
PIR Sensor |
YES |
|
IR Shift |
YES |
|
IRIS Mode |
AES |
|
White Balance |
ATW |
|
AGC |
Auto |
|
WDR |
YES (120dB) |
|
External alarm I/O |
YES (1 input / 1 output) |
|
Operating Temperature |
0℃ ~ 40℃ |
|
Operating Humidity |
Less than 60% relative humidity |
|
Power Source |
(±10%) DC12V / 1A |
|
Optional Peripheral |
Wall-mount bracket (PAVM542-BKT(B)) |
|
Net Weight (kg) |
0.65 |
