Image sensor |
1 / 2.7 "CMOS image sensor |
|
Number of pixels |
1930 (H) x 1088 (V) |
|
Video Frame Rate |
1080P @ 30fps / 1080P @ 25fps |
|
Minimum Sensitivity |
0.1 Lux / F1.8 , 0 Lux (IR LED ON) |
|
Coefficient of S / N |
More than 48dB (AGC OFF) |
|
speed shutter |
1/30 (1/25) sec ~ 1/720000 (1/600000) sec |
|
Lens |
f3.6mm / F1.8 |
|
Angle of Lens |
89 ° (Horizontal) / 46 ° (vertical) / 108 ° (diagonal) |
|
Infrared |
light 24 ball |
|
IR effective distance |
up to 20m |
|
IR Shift |
Yes |
|
IRIS Mode |
AES |
|
White Balance |
AUTO / USER / PUSH / 8000K / 6000K / 4200K / 3200K |
|
AGC |
Customize |
|
Sharpness |
Customize |
|
Flicker less |
50HZ / 60HZ / OFF |
|
BLC |
Customize |
|
Alarms ( I / O) |
Yes (1 in / 1 out) |
|
IP Standard |
IP66 |
|
Operating temperature |
25 ℃ ~ 50 ℃ |
|
Power Source (± 10%) |
DC12V / 0.5A |
|
Current capacity (± 10%) |
N118 160mA (IR LED OFF) / 360mA (IR LED ON) |
