Video System |
NTSC / PAL (auto detection) |
|
Video Compression Format |
H.264 |
|
Video Input |
8 Channels (Composite video signal 1 Vp-p 75 BNC) |
|
Video Loop Out |
8 Channels (Composite video signal 1 Vp-p 75 |
|
Video Output (BNC),Main Monitor |
For stable display |
|
Video Output (BNC),Call Monitor |
For sequence display |
|
Video Output (VGA) |
Built-in VGA interface for LCD monitor(output resolution up to 1600 x 1200) |
|
Audio Input |
4 Channels (Mono) |
|
Audio Output |
2 Channel (Mono) |
|
Multiplex Operating |
Supports live display, recording, playback, backup, and network simultaneously |
|
Maximum Recording Rate(Frame) |
60 IPS @ 704×480 <NTSC> / 50 IPS @ 704×576 <PAL> |
|
Maximum Recording Rate(Field) |
120 IPS @ 704×240 <NTSC> / 100 IPS @ 704×288 <PAL> |
|
Maximum Recording Rate(CIF) |
240 IPS @ 360×240 <NTSC> / 200 IPS @ 360×288 <PAL> |
|
Recording Mode |
Manual / Timer / Motion / Alarm / Remote |
|
Recording Quality Options |
Super Best, Best, High & Normal |
|
Pre-alarm Recording |
YES (8 MB) |
|
HDD Type |
SATA |
|
HDD Storage** |
Up to two HDDs |
|
HDD Quick Cleaning |
Deletes HDD Data Efficiently (1TB within 2 seconds) |
|
Quick Search |
Time / Motion / Alarm search mode |
|
USB Flash Drive Backup |
YES |
|
DVD Writer Backup |
-- |
|
Playback on PC |
Windows Media Player compatible |
|
Network Transfer Format |
H.264 |
|
Ethernet |
10/100 Base-T |
