Pick up Element |
1/3" HR color CCD image sensor with SONY Effio DSP |
|
Number of Pixel |
771(H) x 492(V) / 753(H) x 582(V) |
|
Resolution |
Super High resolution |
|
Min. Illumination |
0.05 Lux / F1.5 |
|
S/N Ratio |
More than 48dB (AGC off) |
|
Electronic Shutter |
1/60 (1/50) to 1/100,000 sec. |
|
Lens |
f6.0mm / F1.4 or f3.8mm / F1.5 |
|
Lens Angle |
54° (for f6.0) or 84.5° (for f3.8) |
|
Color Rolling Suppress |
YES |
|
BLC |
YES |
|
IRIS Mode |
AES |
|
White Balance |
ATW |
|
Video Output |
1.0Vp-p composite, 75Ω |
|
Power Source (±10%) |
DC12V |
|
Current Consumption (±10%) |
70mA |
|
Dimensions (mm)** |
125(O) × 85(H) |
