Pick up Element |
1/3” Color CCD image sensor |
|
Number of Pixel |
976(H) x 494(V) / 976(H) x 582(V) |
|
Resolution |
Up to 700 TV lines |
|
Min. Illumination |
0.05 Lux / F1.4; 0 Lux (IR ON) |
|
IR LED |
56 units |
|
IR Effective Range |
Up to 40 meters |
|
S/N Ratio |
More than 48dB (AGC OFF) |
|
Electronic Shutter |
1/60 (1/50) to 1/100,000 sec. |
|
Lens |
f6.0mm / F1.4 |
|
Lens Angle |
56.6° (Diagonal) / 46.6° (Horizontal) / 34.8° (Vertical) |
|
Iris Mode |
AES |
|
White Balance |
ATW |
|
Video Output |
1.0 Vp-p composite, 75? |
|
Power Source (±10%) |
DC12V |
|
Startup Temperature |
0?~40? |
|
Operating Temperature |
-20?~40? |
|
Current Consumption (±10%) |
70mA (IR OFF), 200mA (IR ON) |
