Sensor |
1/3" HR color CCD image sensor |
|
Number of Pixels |
976(H) x 494(V) / 976(H) x 582(V) |
|
Min. Illumination |
0.1 Lux; 0 Lux (IR ON) |
|
S/N Ratio |
More than 48dB (AGC off) |
|
Electronic Shutter |
1/60 (1/50) to 1/100,000 sec. |
|
Lens |
f3.8mm ~ f9.5mm |
|
Lens Angle |
Wide: 71.4° (Horizontal) / 52° (Vertical) / 92.8° (Diagonal) Tele: 31.8° (Horizontal) / 23.9° (Vertical) / 39.8° (Diagonal) |
|
IRIS Mode |
AES |
|
IR LED |
17 units |
|
IR Effective Distance |
Up to 15 Meters |
|
White Balance |
ATW |
|
AGC |
Auto |
|
IP Rating |
IP66 |
|
Operating Temperature |
-10°C~40°C |
|
Video Output |
1.0 Vp-p composite, 75Ω |
|
Power Source (±10%) |
DC12V |
|
Current / Power consumption (±10%) |
70mA (IR OFF), 220mA (IR ON) |
|
Dimensions (mm) |
97(Ø) × 60(H) |
